The Lowrance Elite FS series delivers professional-grade fish finding and chartplotting capabilities at a mid-tier price point. Anglers gain serious sonar clarity with included Active Imaging and CHIRP technology, plus detailed preloaded C-MAP DISCOVER maps. This fish finder-chartplotter combo supports advanced networking and is ready for game-changing ActiveTarget 2 Live Sonar integration.
The Lowrance Elite FS balances high-performance features like FishReveal overlay and Genesis Live mapping with accessible pricing. Its responsive touchscreen and Ethernet/NMEA 2000 connectivity create a versatile command center. This review examines how the Lowrance Elite FS 7, FS 9, and FS 12 models provide exceptional value for kayak, bass, and offshore anglers seeking premium functionality without premium costs.
Key Points of Lowrance Elite FS Fishfinder
- ACTIVE IMAGING 3-IN-1: See structure and cover with a new level of refined detail with the included Active Imaging 3-in-…
- ACTIVETARGET READY: See high-resolution images of fish swimming around structure and responding to your lure – as it hap…
- FULL NETWORKING: Build the complete Elite Fishing System with integrated wireless, NMEA 2000 and Ethernet connectivity –…
Specifications of Lowrance Elite FS Fishfinder/Chartplotter
| Specification | Lowrance Elite FS 7 | Lowrance Elite FS 9 | Lowrance Elite FS 12 |
| Screen Size | 7″ | 9″ | 12″ |
| Resolution | 800 x 480 pixels | 800 x 480 pixels | 1280 x 800 pixels |
| Brightness | >1,200 nits | >1,200 nits | >1,200 nits |
| Technology | SolarMAX HD TFT | SolarMAX HD TFT | SolarMAX HD TFT |
| Included Transducer | Active Imaging 3-in-1 HDI | Active Imaging 3-in-1 HDI | Active Imaging 3-in-1 HDI |
| Sonar Technologies | CHIRP, DownScan™, SideScan, FishReveal | CHIRP, DownScan™, SideScan, FishReveal | CHIRP, DownScan, SideScan, FishReveal™ |
| ActiveTarget® 2 Support | Yes (transducer sold separately) | Yes (transducer sold separately) | Limited split-screen capability |
| Preloaded Maps | C-MAP® DISCOVER 19,000+ US / 9,400+ CA lakes | Same as FS 7 | Same as FS 7 |
| Custom Mapping | Genesis™ Live | Genesis™ Live | Genesis™ Live |
| Ethernet Ports | 1 | 1 | 1 |
| NMEA 2000® | Yes | Yes | Yes |
| Bluetooth® | Yes (Lowrance app sync) | Yes (Lowrance app sync) | Yes (Lowrance app sync) |
| Wi-Fi | No | No | No |
| Dimensions (W x H x D) | 8.1″ x 4.9″ x 2.9″ | 10.1″ x 6.1″ x 3.1″ | 14.3″ x 8.3″ x 3.3″ |
| Weight | 2.2 lbs | 3.3 lbs | 6.6 lbs |
| Waterproof Rating | IPX7 | IPX7 | IPX7 |
| Mount Type | Gimbal (included) | Gimbal (included) | Gimbal (included) |
| Voltage Range | 10-17V DC | 10-17V DC | 10-17V DC |
| Power Consumption | 2.0A @ 13V | 2.0A @ 13V | 2.5A @ 13.8V |
| Internal Memory | 16GB | 16GB | 16GB |
| Expandable Storage | microSD (up to 128GB) | microSD (up to 128GB) | microSD (up to 128GB) |
Features of Lowrance Elite FS Fishfinder/Chartplotter
A mid-range fishfinder and chartplotter series featuring Active Imaging sonar, C-MAP Contour+ maps, and networking for FS 7/9 models with balanced features and value. Here are its detailed features:
Crystal-Clear Underwater Vision
TheLowrance Elite FS leverages Active Imaging 3-in-1 sonar to deliver photo-like DownScan and SideScan imagery, paired with high-resolution CHIRP returns. FishReveal™ technology dynamically overlays traditional sonar arches onto structure scans, eliminating guesswork in distinguishing fish from cover. For anglers targeting suspended walleye or bass buried in timber, this creates unparalleled situational awareness. The system is live-sonar ready, supporting Lowrance’s ActiveTarget 2 transducer to track fish movements in real time, transforming how anglers approach drop-offs, docks, and grass lines.
Precision Navigation & Custom Mapping
Preloaded C-MAP DISCOVER charts offer 1-foot contours for over 28,400+ North American lakes, revealing hidden ledges, ditches, and humps. The integrated Genesis™ Live function generates real-time bathymetric maps while navigating, allowing users to chart uncharted coves or refine known hotspots. Waypoint management is streamlined via the Lowrance mobile app, enabling offline route planning, anchor alarms, and seamless sharing of GPS coordinates across devices—ideal for tournament pre-fishing or exploratory trips.
Advanced Command Center Capabilities
Networking versatility defines the Lowrance Elite FS. A dedicated Ethernet port shares sonar, waypoints, and maps across multiple displays, while NMEA 2000 integration turns the unit into a vessel hub. Monitor livewell temperatures, fuel levels, or engine diagnostics, and directly control compatible trolling motors (Lowrance Ghost, MotorGuide) or Power-Pole anchors. For offshore safety, the system supports HALO radar (sold separately) to identify navigational hazards, vessels, or weather patterns.
Intuitive User Experience
Engineered for on-water efficiency, the SolarMAX HD touchscreen remains responsive with wet hands or gloves and resists glare in direct sunlight. The IPX7 waterproof rating ensures reliability in downpours or spray. Simplified menus prioritize one-touch access to sonar views, mapping layers, or networking controls. With microSD expandable storage, anglers can load additional maps or save years of custom waypoints without relying on cloud connectivity.
Scalable Performance Ecosystem
The Lowrance Elite FS series grows with an angler’s needs. Start with the bundled Active Imaging transducer, then add ActiveTarget 2 Live Sonar for predator tracking or the S3100 module for enhanced HD imaging. The Lowrance Outboard Pilot integration automates course-holding on offshore drifts, while Bluetooth connectivity syncs data to smartphones for post-trip analysis. This modularity makes the FS a long-term investment, not a fixed solution.
Pros and Cons of Lowrance Elite FS Fishfinder/Chartplotter
| Pros | Cons |
| Plug-and-play mapping: Preloaded 1′ C-MAP contours for 28,400+ lakes provide immediate access to high-detail bathymetry. | FS 12 split-screen limitation: Cannot display ActiveTarget 2 + traditional sonar simultaneously. |
| Future-proof networking: Ethernet & NMEA 2000 support radar, engine data, and trolling motor control (Ghost/Power-Pole). | Storage constraints: Relies on microSD expansion despite 16GB internal memory (competitors offer cloud sync). |
| Genesis Live mapping: Creates real-time custom charts directly on the unit – ideal for unmapped backwaters. | Power consumption: FS 12 draws 2.5A @ 13.8V – may require electrical upgrades for kayaks. |
| Mobile app integration: Plan routes offline, set geofences, and sync waypoints via Bluetooth. | Wi-Fi absence: Forces manual updates via SD card vs. wireless convenience. |
Step-by-Step Lowrance Elite FS Setup & Installation Guide
Phase 1: Pre-Installation Preparation
Gather Tools & Components:
Lowrance Elite FS unit, power cable (16 AWG recommended), transducer, mounting hardware kit, NMEA 2000 starter kit (if networking).
Tools: Drill, marine sealant (e.g., 3M 5200), hole saw kit, screwdrivers, wire strippers, multimeter.
Plan Mounting Locations:
Display: Choose the dash location visible while steering. Ensure clearance for FS 9’s larger footprint (9.3″ x 6.1″).
Transducer: Select hull position ahead of propellers/strakes, avoiding turbulent water (critical for high-speed depth readings).
Power Source: Connect directly to battery (with 3A fuse) ≤ 6 ft away to prevent voltage drop.
Phase 2: Display Unit Installation
Mount Bracket:
Secure swivel bracket using stainless screws. For fiberglass, pre-drill holes and apply sealant to prevent cracking.
Run Cables:
Route power/transducer cables through the dash/conduit. Avoid sharp bends or proximity to engine wires (reduces interference).
Phase 3: Transducer Mounting
Attach Transom Bracket:
Position Active Imaging transducer 3/8″ below hull bottom. Level horizontally (±3° tolerance). Mark screw holes.
Secure & Seal:
Drill pilot holes, apply sealant, and fasten the bracket. Snap the transducer into place.
Phase 4: Electrical Connections
Power Wiring:
Connect the red wire to the battery (+) terminal.
Connect the black wire to the battery (-) terminal.
Install an inline fuse ≤ 18″ from the (+) terminal.
Ground Loop Prevention:
Twist power cables together to minimize electromagnetic interference.
Phase 5: Networking & Accessories (Optional)
NMEA 2000 Setup:
Connect backbone cables between the Lowrance Elite FS, battery (via power tap), and accessories (e.g., Ghost trolling motor). Terminate both ends.
Add ActiveTarget Live:
Mount the Live transducer on the trolling motor. Connect to Lowrance Elite FS via Ethernet cable.
Phase 6: Initial Startup & Calibration
System Check:
Power on the unit. Confirm transducer detection (Settings > Sonar > Installation).
Calibrate Sensors:
Access Settings > Network > Data Sources > Calibrate. Follow on-screen prompts for compass, water speed.
Test on Water:
Verify depth readings at idle and high speed. Adjust the transducer angle if readings drop >8 mph.
Unboxing the Lowrance Elite FS: What’s in the Box?
Core Components:
Display Unit:
Lowrance Elite FS 7 (7-inch) or FS 9 (9-inch) touchscreen display with tilt-swivel bracket.
Pre-installed SD card slot (supports C-MAP updates/chart sharing).
Transducer:
Active Imaging™ 3-in-1 Skimmer Transducer (standard in bundles):
CHIRP Traditional/SideScan/DownScan capabilities.
15-pin connector, 20 ft cable length.
Power/Data Cables:
16 AWG power cable (20 ft) with inline fuse holder.
Ethernet cable (for networking radar/ActiveTarget).
Mounting Hardware:
Stainless steel screws, nuts, washers, and cable clips.
Transom mount bracket with adjustable tilt mechanism.
Included Accessories:
Quick-start guide & safety manual.
Preloaded Maps:
C-MAP Contour+ US inland charts (19,000+ lakes) or regional coastal charts (varies by SKU).
Protective cover (non-sun shield type).
What’s Not Included:
NMEA 2000 Starter Kit: Required for trolling motor/sensor networking (sold separately).
ActiveTarget™ Live Transducer: Live sonar requires a $1,499 add-on.
Sun Cover: Aftermarket hood recommended for glare reduction.
RAM Mount: Standard bracket suits flat surfaces; complex dash setups need third-party mounts.
User Experience and Reviews About Lowrance Elite FS Fishfinder/Chartplotter
| Category | Positive Feedback | Negative Feedback |
| Performance & Features | Live Sonar Clarity: ActiveTarget 2 integration (when purchased) provides “game-changing” real-time fish tracking, increasing hookup rates by 40% in murky water. | Transducer Limitations: Default Active Imaging 3-in-1 struggles at speeds >7 knots; requires repositioning for reliable deep-water readings. |
| Usability & Setup | Intuitive Workflow: Touchscreen responsive with wet hands; customizable split-screens reduce menu diving. | Model Inconsistencies: FS 12 lacks ActiveTarget split-screen; FS 7/9 have lower-resolution TFT screens (vs. IPS on FS 10/12) |
| Support & Value | Budget-Friendly Pro Tools: Mid-tier pricing with HDS-grade networking (Ethernet/NMEA 2000) appeals to tournament anglers. | Warranty & Reliability: Multiple reports of “Sonar Version 0.0.0” software crashes post-warranty, with repair costs up to 60% of the unit price. |
Key Takeaways of Lowrance Elite FS Fishfinder/Chartplotter
Who Should Buy Lowrance Elite FS Fishfinder/Chartplotter?
- Kayak anglers and small-boat owners need a compact, reliable unit (FS 7 ideal).
- Tournament fishermen prioritize split-screen clarity and networking (FS 9 recommended).
- Budget-focused anglers wanting Live Sonar compatibility without premium Humminbird/Garmin costs.
- Users value preloaded C-MAP Contour+ maps over custom mapping creation.
- Boaters are integrating trolling motors or radar via NMEA 2000/Ethernet networking.
Who Should Skip the Lowrance Elite FS?
- Anglers demand the highest-resolution imaging (e.g., Garmin Livescope Ultra clarity).
- Kayakers needing ultra-compact units (consider Elite PS or Hook Reveal instead).
- Saltwater boaters require rugged, sunlight-readable screens (Garmin ECHOMAP Ultra superior).
- Users are unwilling to buy ActiveTarget separately ($1,500+) for Live Sonar functionality.
- DIY mappers needing on-unit Genesis Live detail (Humminbird Mega Live excels here).
FAQs About Lowrance Elite FS Fishfinder/Chartplotter
Is the Lowrance Elite FS compatible with ActiveTarget Live Sonar?
Yes, the Lowrance Elite FS supports ActiveTarget Live Sonar but requires a separate purchase (~$1,499). It connects via Ethernet cable for real-time forward, down, and scout views.
What maps come preloaded on the Lowrance Elite FS?
The unit includes C-MAP Contour+ charts with 1-foot depth contours for 19,000+ U.S. lakes and 9,400+ Canadian lakes. Genesis Live allows on-the-fly custom mapping.
Can the Lowrance Elite FS control a trolling motor?
Yes, via NMEA 2000 networking. It integrates with Motorguide Xi5, Ghost, and compatible Minn Kota trolling motors for heading lock and route following.
Does the Lowrance Elite FS work in saltwater?
Yes, with limitations. Its Active Imaging 3-in-1 transducer handles saltwater but may lose bottom tracking above 8 knots. For offshore use, pair with HALO radar (sold separately).
What’s the difference between Lowrance Elite FS 7 and FS 9?
Only screen size: FS 7 has a 7-inch display (800×480 pixels), FS 9 has a 9-inch (1280×720) display. All features (sonar, networking, mapping) are identical. Choose based on the dash space and visibility needs.
Recommended Accessories for Lowrance Elite FS Fishfinder/Chartplotter
Enhance your Lowrance Elite FS with crucial accessories. An Active Imaging 3-in-1 transducer provides detailed sonar. For live views, consider an ActiveTarget Live Sonar system. An NMEA 2000 Starter Kit enables networking with other devices. Protect your display with a sun cover. For convenient control of a Ghost trolling motor, explore its dedicated remote. Various mounting kits and brackets ensure secure installation.
